Area of Refuge/Area of Rescue Emergency System
Overview: Area of Refuge Emergency Communication Systems
Area of Refuge Communication Systems
Cornell’s 4200 and 4800 Series area of refuge systems (area of rescue) provide emergency communication between call stations and annunciators. When combined with appropriate ARA signage, Area of refuge assistance systems from Cornell meet ADA, IBC and NFPA regulations.
4200 Series Analog Area of Refuge System
The 4200 Series Analog Area of Refuge System offers ONE-WAY communication from the control station to the caller.
4800 Series Digital Area of Refuge System
The 4800 Series Analog Area of Refuge System offers TWO-WAY communication bewteen the control station and the caller.
A reliable and instantaneous communication tool means the difference between safety and life-threatening danger during an emergency situation. Cornell Communications, your number one provider of high-quality emergency communication systems and nurse call systems, is proud to offer our full line of area of refuge systems, perfectly suited for any building with multiple floors and staircases.
Buildings around the globe use Cornell’s time-proven area of rescue emergency intercom systems to:
- Ensure individuals with limited mobility are safe in emergency situations and have a method to call for assistance
- Ensure schools and other public venues have a system for individuals to call for help in dangerous situations
- Alert first responders to individuals in distress
- Offer communication with first responders
|System Design||System Technology||System Signage|
|System Cables||ADA Requirements||Local Requirements|
4200 Series Analog Area of Rescue Emergency Communication System
The 4200 Analog Emergency Communication System from Cornell operates as indicated above with individual buttons for each alarm station or zone. Our 4200 Series analog area of refuge system can be sized from 4 to 20 zones in multiples of 4 zones. The system only allows for one Master Control Panel and communicates to the remote 911 center via text and pre-reocrded voice messages only.
|Get a Quote||Overview & Brochures||Components & Product Sheets|
|Architectural Specs||Wiring Diagrams||Design Guide|
4800 Series Digital Area of Rescue Emergency Communication System
The 4800 Series Digital Emergency Communication system was developed to meet the requirements of the International Building Code (IBC) adopted by the US in 2015. It supports up to 255 call stations and 5 master panels; lending itself to larger buildings. It also provides for two way voice communication both in the building and with the 911 Center. Buy 4800 ARA replacement parts online or compare 4800 ARA signage.
|Get a Quote|
|Overview & Brochure||Components & Product Sheets||Architectural Specs|
|Wiring Info||Installation Manual||Design Guide|
Area of Refuge System Design & Configuration
Cornell Communications helps design area of refuge systems for businesses across the country. Whether you opt for our easy to use nurse call and area of refuge system quote tools, or you choose to contact our area of refuge experts, Cornell Communications is here to help you design the perfect area of refuge system for your community. Work with Cornell and ensure you have all area of refuge system features and functions required by law.
Call Stations to Request Assistance
Highly intuitive, vandal-resistant call stations are typically placed in each stairwell or adjacent to the elevators to provide hands-free emergency voice communication at the press of a button. A tone and flashing light assure the caller their call for help has been received, and a voice confirmation response assures them help is on the way.
Calls are Communicated to a Master Panel or to Offsite Emergency Response Centers
When the call is activated it is indicated on the master panel--typically located near the building entrance, Fire Alarm Panel or in the Security office. Some buildings will mount additional panels at secondary building entrances (or at all entrances). The person hearing the tone selects the alarm zone calling for assistance, talks to the caller and indicates when help will arrive. If the call is not responded to in a time set by the system, the call is forwarded to an offsite 911 emergency response center.
A 24VDC Power Supply
The system is centrally powered with a battery backup to ensure operation in times of emergency.
Custom cabling is available in plenum and non-plenum styles, along with Fire Resistant Cable for the 4200 analog system.
Area of Refuge Technology
Cornell offers an analog and a digital area of rescue communication system. Emergency communication systems were first mandated by the American with Disabilities Act (ADA) in 1993 and later made mandatory in all multi-story buildings by the International Building Code (IBC) adoption in 2015.
Which system should you select?
The IBC code now requires two-way communication between the offsite 911 center and the person calling for assistance. Building codes are implemented locally and enforced by the Authority Having Jurisdiction (AHJ). Certain AHJ’s interpret two-way voice communication between both parties as something which can only be accomplished with an intercom (as the Model 4800 Digital system has). Other AHJ’s feel text or recorded messages meet that requirement and say the Model 4200 Analog system is adequate. You will need to consult with your AHJ to determine the specific requirements for your locality.
Area of Refuge Emergency System Signage
Signage is required by building codes, as well as ADA and NFPA 101 regulations, to ensure the call stations and safe refuge areas can be readily found. Signage also includes instructions to call for assistance. Cornell's 4200 & 4800 Series Area of Rescue Assistance systems come with all appropriate signage when ordered as a complete system. Individual Area of Rescue or Refuge signage is also available.
Area of refuge signage from Cornell meets and exceeds all ADA specifications; including entry and exit direction and location signs, powered signs (plus a battery back up) and RADIANCE photoluminescent room identification signs. Cornell signage is available in all three ADA-compliant forms:
- Directional signs show the way to the alarm station and safe refuge area
- Lighted Room Location signs to identify the refuge area
- Instruction signs indicating how to operate the alarm station or call for assistance
Area of Rescue System Custom Cable
Simplify your installation with custom cables designed to meet your specifications.
4200 Analog System
- CB-4200 Smartwire – Connects the Master Station to the Call Stations
- CB-4004 – Connects the Power Supply to the Master Panel
4800 Digital System
- CB-4800 – Connects the Master Station to the Call Stations with Fire Resistant Coating
- CB-4802 – Master Panel to Remote Masters and Master Panel to Call Stations.
- CB-4804 – Master Panel to Power Supply for Power
- CB-4002 – Master Panel to Power Supply for Fault Detection
The Americans with Disabilities Act requires areas of rescue assistance or places of refuge where people can wait for emergency personnel to arrive. Areas of rescue on each floor of a multistory building, such as a hospital, allow people who cannot use the stairs to call for help, receive instructions, and wait for assistance during an evacuation. Clear signage reading “Area of Rescue Assistance” is required, along with instructions for using the two-way communication system.
The emergency communication system must be usable for people with hearing impairments, speech impairments, and difficulty accessing. An area of rescue system with both visible and audible signals allows the people with hearing or speech difficulties to receive information. A light indicating the call was received and a voice intercom makes the system more accessible in an emergency. An emergency call system with no handset also makes it easier for people with difficulty reaching or grasping.
Area of Refuge Requirements by State
Not sure if your new or existing facility requires an area of refuge system? Cornell breaks down the area of refuge requirements by state making it easy to understand state and local codes.
While most states follow the International Building Code (IBC), some states might follow a different version of the IBC. Some states even have their own unique exceptions to the IBC. IBC regulations on Area of Rescue and Area of Refuge systems are nuanced, sometimes even varying by county to county or city to city. Cornell Communications is the expert on building, fire and safety codes regarding Area of Refuge and Area of Rescue systems. We’re here to help your business understand the complexities of Area of Refuge requirements in your state.
